ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor

Brand Name : GDHY

Model Number : C41701664KTC2201-01

Certification : SGS,ISO

Place of Origin : GUANGZHOU, CHINA

MOQ : 20 PCS

Price : 107 USD/ PCS

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 1000 PCS /MONTH

Delivery Time : 14 DAYS

Packaging Details : CARTON WITH FOAM BOX AND ANTI-CORRSION PROTECTION

BRAND NAME : GDHY

CHARACTERISTICS : WATER COOLED, CONDUCTION COOLED, EXCELLENT HEAT DISSPATION.

CORE : IMPORTED COPPER FOIL

CAPACITANCE VALUE : 0.66μF

RATED POWER : 200KVAR

RATED VOLTAGE : 700V

OPERATION TEMPERATURE : -40℃～85℃

CAPACITY TOLERANCE : ±10%

LIFE EXPECTANCY : 100000h at UN and 70℃,30000h at Urms

DIMENSION : 68*30*30.2 MM

PRINTING METHOD : LASER MARKING

QUALITY CERTIFICATE : ISO 9001

MATERIAL : BRONZE

APPLICATION FIELD : NEW ENERGY FIELDS; TRANSPORTATION FACILITIES; HIGH POWER INDUSTRIAL FACILITIES: QUALITY CONTROL: IQC, SPC, INSPECTION, WAREHOUSING

COMPANY HISTORY : SINCE 1998

EXPERIENCE : OVER 22 YEARS

INSTALLATION : THROUGH HOLE

ADVANTAGE : KEEP LOW DF AND LONG LIFE EXPECTANCY

Contact Now

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film CapacitorC41-TC2 0.66UF/700V/200KVAR ALCON FP-4-150-SM/SP CELEM CSM 150 FILM CAPACTIOR RESONANT CONDUCTION COOLED



Technical Parameter



Reference Standards GB/T 3984-2004 IEC 60110.1
Operating Temperature Range -40℃～85℃
Capacity Range 0.66μF
Rated Power 200kVar
Rated Voltage 700VAC
Capacity Tolerance  ±10%
Test Voltage between Terminals 1.5UNAC 10s
2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy 100000h at UN and 70℃,30000h at Urms



Specification download: C41-TC2.pdf





Application

Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.

.

Feature

● Conduction water-cooled

● Polypropylene dielectric

● Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt,

● Can bear large current, excellent heat dissipation



ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor



Product Shape

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor



Workshop&Equipment

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor

Prodcution

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor



Packing

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor



Exhibition

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor

Certification

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor





Comparison

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor
