Alcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor

Name: Alcon FP20400 700Vrms 500nF Conduction Cooled Capacitor
Brand: GDHY
Price: 55 USD

Buy cheap Alcon FP-20-400 700Vrms 500nF Conduction Cooled Capacitor product

Brand Name : GDHY

Model Number : C41701504KBA2401-01

Certification : SGS,ISO

Place of Origin : China

MOQ : 20pcs

Price : USD55/PC

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 1000PCS/ MONTH

Delivery Time : 14days

Capacity : 0.5uF

Voltage : 700VAC

Size : 68mm*30mm*30.2mm

Power : 400KVAR

Frequency : 260-336KHZ

Model : C41701504KBA2401-01

Brand : GDHY

Terminal : Copper

Capacity Tolerance : ±5% ~ ±10%

Material : Polypropylnen Film&Copper

Series : Power Film Capacitor

Place Of Original : China

Max Irm : 650A

Application : Induction Heating, Heat Treatment, Plasma Applications, Resonant Circuits, Medical Imaging, Wireless Power Transfer, EV (electric Vehicle) Charging, IPT, High Frequency Inverters,etc.

Contact Now

C41-BA2 0.5uF/700Vrms/400kVar( Alcon FP-20-400/Celem CSP 150/400) Power Film Capacitor for Bolt Heating

Technical Parameter

Reference Standards	GB/T 3984-2004 IEC 60110.1
Operating Temperature Range	-40℃～85℃
Capacity Range	0.66μF～2.4μF
Capacity Range	400kVar
Rated Voltage	400-800VAC
Capacity Tolerance	±5% ~ ±10%
Test Voltage between Terminals	1.5UNAC 10s 2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor	tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance	R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy	100000h at UN and 70℃,30000h at Urms

Application

Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.

Features

● Conduction water-cooled

● Polypropylene dielectric

● Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt,

● Can bear large current, excellent heat dissipation

Product Picture
