P10mm 630V104J CBB22 0.1uF CBB Polypropylene Film Capacitor

Product Categories

Guangdong Huayu Electronic Company Limited

Contact Now

Name: P10mm 630V104J CBB22 01uF CBB Polypropylene Film Capacitor
Brand: GDHY
Price: 0.1 USD

Brand Name : GDHY

Model Number : CBB22 104J630V 10

Certification : SGS,ISO

Place of Origin : China

MOQ : 100Kpcs

Price : USD0.1/PC

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 1KKpcs/Month

Delivery Time : 14days

Capacity : 0.1uF

Voltage : 630V

Size(W*T*H) : 13*6.0*10.0mm

Pitch : 10mm

Model : CBB22 104/630V 10

Name : CBB22 104J630V 10

Brand : GDHY

Terminal : CP Wire

Capacity Tolerance : ±5% ~ ±10%

Material : Polypropylnen Film

Series : CBB Polypropylene Film Capacitor

Place Of Original : China

Supplier Type : Manufacturer

Lead : 0.6mm

Color : Brown

Encapsulation : Power

Packaging Type : Through Hole

Application : Widely used in high frequency, direct current and pulse circuits,Led Driver,Led Light

Contact Now

CBB22 630V104J 0.1uF Metallized Polypropylene Film Capacitor MPP Film Capacitor CBB kondensator z folii polipropylenowej for LED Driver

Technical Parameter

Reference Standards	GB/T 10190(IEC 60384-16)
Climate Category	40/085/21
Operating Temperature Range	-40℃～+85℃,Tmax 105℃
Capacity Range	0.01～2.2μF
Rated Voltage	100V,250V,400V,630V(DC)
Capacity Tolerance	±5%(J)；±10%(K)；±20%(M)
Withstand voltage	2.0UR 5S (@20±5%)
Dissipation Factor	tgδ≤0.0010 (@20℃, 1KHz)
Insulation Resistance	≥30000MΩ(at 20℃ 100VDC 1Min)

Application

Widely used in high frequency, direct current and pulse circuits

Features

● Metallized polypropylene inner series structure

● Self-healing

● It can be bear high voltage

● Flame retardant epoxy resin wrapping

Product Picture
