472nf 1000VDC High Voltage Metallized Polypropylene Film Capacitors

Name: 472nf 1000VDC High Voltage Metallized Polypropylene Film Capacitors
Brand: GDHY
Price: 0.1 USD

Brand Name : GDHY

Model Number : CBB81 4721KV

Certification : SGS,ISO

Place of Origin : GUANGZHOU, CHINA

MOQ : 20KPCS

Price : 0.1 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS/ MONTH

Delivery Time : 15 DAYS

Packaging Details : CARTON

PLACE OF ORIGIN : GUANGZHOU, CHINA

SUPPLIER TYPE : ORIGINAL MANUFACTURER

TYPE : POLYPROPYLENE FOIL CAPACITOR

MODEL : CBB81 4721KV21

MATERIAL : Metallized polypropylene film

OPERATION TEMPERATURE : -40℃～105℃

CAPACITANCE : 472nF

TOLERANCE : ±5%,±10%,±20%

RATED DC VOLTAGE : 800VDC,1000VDC,1200VDC,1600VDC,2000VDC

PITCH : 15MM

DIMENSION : 24*13.5*20MM

ENCAPSULATION : Flame retardant epoxy resin powder encapsulation

PACKAGE TYPE : non-inductive construction

COLOR : Red

CHARACTERISTICS : Small tgδ, low internal temperature rise

CERTIFICATION : VDE, UL, SGS，ISO

APPLICATION : Display, Color TV Reverse Circuit Suitable for High Pulse and High Current Circuits;Suitable for High Pulse and High Current Circuits

OEM/ODM : both

Specification data : Supply if need

Contact Now

472nf 1000VDC High Voltage Metallized Polypropylene Film Capacitors

Technical Parameter

Reference Standards	GB/T 14579 (IEC 60384-17)
Climate Category	40/85/21
Operating Temperature Range	-40℃~85℃,Tmax105℃
Capacity Range	0.001uf-0.1uf
Rated Voltage	800VDC,1000VDC,1200VDC,1600VDC,2000VDC
Capacity Tolerance	±5%,±10%,±20%
Withstand voltage	Vt-t:1.75Un 5S (at 20±5℃)
Insulation Resistance	R C≥3000s；at 1000VDC;25℃ ±5℃,60s

Application

Display, Color TV Reverse Circuit Suitable for High Pulse and High Current Circuits;

Suitable for High Pulse and High Current Circuits

Features

● Metallized polypropylene film foil dielectronic

● Non-inductive winding structure

● Flame retardant e poxy resin powder encapsulation

● Small tgδ, low internal temperature rise

● Negative electricity capacity temperature ratio

Product picture

472nf 1000VDC High Voltage Metallized Polypropylene Film Capacitors

Product shape

472nf 1000VDC High Voltage Metallized Polypropylene Film Capacitors

Production

472nf 1000VDC High Voltage Metallized Polypropylene Film Capacitors

Workshop& Equipment

472nf 1000VDC High Voltage Metallized Polypropylene Film Capacitors

Packing method

472nf 1000VDC High Voltage Metallized Polypropylene Film Capacitors

Certificate

472nf 1000VDC High Voltage Metallized Polypropylene Film Capacitors

Exhibition

472nf 1000VDC High Voltage Metallized Polypropylene Film Capacitors
