0.47uf 474/400v P15 Polypropylene Film Capacitors For Pulse Circuits

Product Categories

Guangdong Huayu Electronic Company Limited

Contact Now

Name: 047uf 474400v P15 Polypropylene Film Capacitors For Pulse Circuits
Brand: GDHY
Price: 1 USD

Brand Name : GDHY

Model Number : CBB22 0.47UF 400V P=15MM

Certification : SGS,ISO

Place of Origin : GUANGZHOU, CHINA

MOQ : 100KPCS

Price : PLEASE CONTACT US FOR MORE DETAILS

Payment Terms : Western Union, T/T, MoneyGram

Supply Ability : 1KK PCS/MONTH

Delivery Time : 15 WORKING DAYS

Packaging Details : PLASTIC BAG

TYPE : METALLIZED POLYPROPYLENE FILM CAPACITOR

BRAND : GDHY

CAPACITANCE : 0.47UF

RATED VOLTAGE : 400VDC

PITCH : 15MM

DIMENSION : MAX18.0*8.5*12.5 MM

TOLERANCE : ±5%(J);±10%(K)

LEAD DIA : 0.8MM

CERTIFICATION : SGS, ISO

APPLICATION : PULSE CIRCUITS

Contact Now

0.47uf 474/400v P15 Polypropylene Film Capacitors For Pulse Circuits CBB 474J400V FILM CAPACITOR 5% P=15MM EPOXY RESIN COATING

Technical Parameter

Capacitance	0.47μF
Rated Voltage	400VDC
Pitch	15MM
Reference Standards	GB/T 10190(IEC 60384-16)
Climate Category	40/085/21
Operating Temperature Range	-40℃～85℃
Capacity Tolerance	±5%(J);±10%(K)
Withstand voltage	Vt-t:1.6UN 5S (at20 ±5%)
Dissipation Factor	tgδ≤0.0010 (20℃, 1KHz)
Insulation Resistance	C>0.33μF RCN≥30000S (at20℃ 100VDC 1Min)
Maximum Pulse Rise Time (dv/dt)	300(V/μS)

Application

● Designed for high frequency and high current applications, DC/AC, etc.

● Suitable for S-correction circuits of the display equipment

Feature

● Flame retardant epoxy resin powder encapsulation

● Prompt delivery, quality approved

● Resistance to high voltage, small tgδ, low temperature rise

● Good appearance consistency

● Non-inductive winding structure

Product Picture
